Shelly Outdoor Plug S Gen3
Shelly Outdoor Plug S Gen3
Impossible de charger la disponibilité du service de retrait
Caractéristiques principales
- Prend en charge jusqu'à 12 A (2500 W)
- Certifié Matter
- Prise en charge d'Apple Homekit : Contrôlez les dispositifs connectés à l'aide de l'application Apple Home ou de Siri
- Mesure de la puissance(avec Shelly App)
- Classe de protection : IP44
- Indicateur LED multicolore
- Mémoire flash : 8 Mo et puce Shelly
- Scripts
- Prend en charge les programmations, scènes et actions locales
- Excellente compatibilité avec les systèmes et applications d'automatisation domotique tiers, y compris l'application Shelly Smart Control.
- Peut servir de répéteur de portée Wi-Fi et de passerelle BLE
Specifications
|
Quantity |
Value |
|
Physical |
|
|
Size (HxWxD): |
56x56x103 ±0.5 mm / 2.21x2.21x4.55 ±0.02 in |
|
Weight: |
85 ±1 g / 3 ±0.04 oz |
|
Compatible sockets: |
CEE 7/1, CEE 7/3 (Type F / Schuko) or CEE 7/5 (Type E) |
|
Compatible plugs: |
CEE 7/2, CEE 7/4 (Type F / Schuko), CEE 7/7, CEE 7/16 (Type C) or CEE 7/17 |
|
Shell material: |
Plastic with Silicone Ruber Protective Cover for the Outlet |
|
Color: |
Mocha |
|
Environmental |
|
|
Ambient temperature: |
-25°C to 51°C / -13°F to 125°F |
|
Humidity |
15% to 85% RH |
|
Max. altitude |
2000m / 6562 ft |
|
Glow-wire temperature: |
750°C |
|
Ingress Protection: |
IP44 |
|
Required forced cooling: |
No |
|
Electrical |
|
|
Power supply: |
230 V~ 50/60 Hz |
|
Power consumption: |
< 1 W |
|
Rated impulse-withstand voltage: |
2500 V |
|
Output circuits ratings |
|
|
Max. switching voltage: |
230 V~ |
|
Max. switching current: |
12 A |
|
Max. output power: |
2500 W (resistive load only) |
|
Number of switching cycles: |
10000 |
|
Overvoltage category: |
II |
|
Duty-type: |
S1 |
|
Switch type: |
One-way |
|
Switch configuration: |
SPNO (single-pole, normally-open) |
|
Type of circuit disconnection: |
Micro |
|
Sensors, meters |
|
|
Internal-temperature sensor: |
Yes |
|
Voltmeter (AC): |
Yes |
|
Ammeter (AC): |
Yes |
|
Power and energy meters: |
Yes |
|
Radio |
|
|
Wi-Fi |
|
|
Protocol: |
802.11 b/g/n |
|
RF band: |
2401-2473 MHz |
|
Max. RF power: |
<10 dBm |
|
Wi-Fi Range: |
Up to 50 m / 164 ft outdoors, up to 30 m / 98 ft indoors (depending on local conditions) |
|
Bluetooth |
|
|
Protocol: |
4.2 |
|
RF band: |
2402 - 2480 MHz |
|
Max. RF power: |
< 4 dBm |
|
Range: |
Up to 30 m / 98 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions) |
|
Microcontroller unit |
|
|
CPU: |
ESP-Shelly-C38F |
|
Flash: |
8 MB |
|
Firmware capabilities |
|
|
Webhooks (URL actions): |
20 with 5 URLs per hook |
|
Scripting: |
Yes |
|
MQTT: |
Yes |
|
CoAP: |
No |
